Product Details
Place of Origin: China dongguan
Brand Name: Mento
Certification: ISO9001/ISO14001
Model Number: K3205
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: W1000mmxD1380mmxH1600mm(without foot 100±20mm)
Delivery Time: 3week
Payment Terms: on line, L/C, T/T
Supply Ability: 1000/month
Inspection Area: |
Up To 610mm X 460mm |
Resolution: |
5um |
Programming: |
Easy-to-use Drag And Drop |
Lighting Type: |
LED |
Power Supply: |
AC 100-240V, 50/60Hz |
Inspection Speed: |
Up To 1000mm/s |
Camera Type: |
High-resolution CCD |
Inspection Area: |
Up To 610mm X 460mm |
Resolution: |
5um |
Programming: |
Easy-to-use Drag And Drop |
Lighting Type: |
LED |
Power Supply: |
AC 100-240V, 50/60Hz |
Inspection Speed: |
Up To 1000mm/s |
Camera Type: |
High-resolution CCD |
| 3D Solder Paste Inspection | ||
| Device model | K3205 | |
| Detection capacity | Detection items | Miss print, over solder, insufficient solder, solder bridging, solder paste tailing, shape anomany, offset |
| Scanning method | Stop&Go | |
| Optical system | Camera | 5MP high speed color industrial camera |
| Light Source | Dual DLP light source (raster phase shift technology) and red, green and blue (RGB) light source | |
| Resolution | 10μm & 15um (optional) | |
| Detection performance | Height accuracy (calibration module) | 1μm (using standard calibration block) |
| Volume repeatability | <1% (standard verification block, 3Sigma) | |
| Maximum Plate Bending Compensation Value | ±3mm | |
| Detection Capability GRR | <10%at6o(+50%tolerance, 5μm resolution) | |
| Maximum detection height | 500μm | |
| Solution to shadow problem | Phase shift technology & bidirectional 3D Structured Light system | |
| Plate bending real-time compensation method | Plate Bend Compensation (Z-Tracking+Pad Referencing) | |
| Test screen | Color (3D and 2D images displayed together) | |
| Driving equipment | Servomotor+Screw Guide | |
| Moving speed | 800mm/s | |
| Minimum measurable product size | 50mmx50mm | |
| Maximum product measurable size | 400mmx500mm | |
| PCB thickness | 0.5~6mm | |
| Track width adjustment | Automatic width adjustment, manual width adjustment | |
| Circuit board conveying/fixing | Belt conveyor/pneumatic clamp fixing | |
| Conveying direction | From left to right, right to left | |
| Orbital height | 900±20mm | |
| Computer Configuration | Mainframe | CPU: Intel i5, RAM: DDR4-16G, GPU: GTX1660-6GB, SSD:250G, HDD: 2T |
| Monitor | 22"LED | |
| Operating system | Ubuntu | |
| Parameters | Overall size | W1350xD1000xH1600mm (excluding alarm light) |
| Weight | 1100KG | |
| Power source | AC220V/50~60Hz/2000W | |
| Air Pressure | 0.5Mpa | |
| Software Supported Input Formats | Support Gerber format (274X), ODB++ | |
| Statistical management tools |
Histogram,X-bar&R -Chart ,X-bar&S -C hart ,C p&C pk, %Gage R & R,SPI Daily/Weekly/Monthly Reports, real-time SPC& Multiple Display |
|
| Environmental requirements | Temperature: 5~40℃, relative humidity: 25%~80% (no frost) | |
| Upstream and downstream equipment communication | Standard SMEMA interface | |
Our machine runs on the Windows operating system, making it a versatile option for any workspace. You can rest assured that our technology is up-to-date and easily integrated into your existing production line.
With an impressive inspection speed of up to 1000mm/s, our machine is one of the fastest on the market. This means you can save valuable time and increase your throughput without sacrificing accuracy.
The lighting type of our machine is LED, which is known for its long lifespan, low energy consumption, and high brightness. This type of lighting ensures that your inspections are precise and consistent, regardless of the environment you are working in.
Our software is designed with an intuitive GUI, so you don't need to be a computer expert to operate the machine. The user-friendly interface allows you to easily navigate through the inspection process, making it simple to train new staff members.
Our 3D Automated Optical Inspection Machine is the perfect choice for those looking to improve their optical inspection methods. With its advanced technology and user-friendly design, this machine is an investment that will pay off in increased productivity and accuracy.
This smt inspection equipment, 3d automated optical inspection machine is designed to make inspections easy and efficient.
| Technical Parameter | Value |
|---|---|
| Inspection Area | Up To 610mm X 460mm |
| Lighting Type | LED |
| Inspection Speed | Up To 1000mm/s |
| Software | Intuitive GUI |
| Inspection Type | 2D And 3D |
| Operating System | Windows |
| Programming | Easy-to-use Drag And Drop |
| Resolution | 5um |
| Power Supply | AC 100-240V, 50/60Hz |
| Connectivity | Ethernet, USB |
The Automated Optical Inspection Machine is equipped with advanced features that make it suitable for a wide range of product application occasions and scenarios. This product is ideal for PCB manufacturers who require a fast and efficient inspection process to ensure the quality of their products. The inspection speed of the machine is up to 1000mm/s, making it a perfect choice for manufacturers with high production rates.
The Mento Automated Optical Inspection Machine can inspect PCBs with an inspection area of up to 610mm X 460mm, which is a significant advantage over other inspection machines available in the market. The inspection type of the machine is 2D and 3D, making it possible to inspect even the most complex PCBs with ease. The lighting type of the machine is LED, which provides excellent illumination and ensures accurate inspection results.
The operating system of the Automated Optical Inspection Machine is Windows, which is a user-friendly operating system that is easy to navigate, making the machine simple to operate. The product is available at a negotiable price, and the minimum order quantity is only 1, making it an accessible product for small and large manufacturers alike.
The supply ability of the Mento Automated Optical Inspection Machine is 1000/month, making it possible for manufacturers to order as many units as they require. The delivery time of the product is only 1 week, ensuring that manufacturers can receive their orders promptly. The payment terms for the product are on line, making it easy for customers to order and pay for the product online.
In conclusion, the Mento Automated Optical Inspection Machine is an excellent product for PCB manufacturers who require a fast, efficient, and accurate inspection process. The product is suitable for a wide range of product application occasions and scenarios, making it a versatile and reliable product. If you are in need of a PCB inspection machine, the Mento Automated Optical Inspection Machine is an excellent choice.
The Automated Optical Inspection Machine product comes with comprehensive technical support and services to ensure optimal performance and productivity. Our team of experienced technicians and engineers are available to provide assistance with installation, training, troubleshooting, and maintenance. We offer remote support, on-site support, and customized service packages to meet the specific needs of our customers.
